Trek FX 2 Stagger Disc

Trek FX 2 Stagger Disc
  • Color: Satin Lithium Grey
  • Color: Satin Viper Red
$899.99
Please select options
In Store / Curbside Pickup Only. Bike Orders are typically ready in 2 – 5 days*. *Bikes may need to be built or transferred from another location. This may add extra processing time.

Details

FX 2 Disc is a stylish and versatile hybrid bike with hydraulic disc brakes that let you stop on a dime and ask for change, even when the weather isn't cooperating.

The stepthrough frame makes it easy to hop on and go, and hop off when your ride is over.

Raining cats and dogs? That doesn't keep you from riding. The FX series includes mounts for fenders to keep you dry in wet weather.

Train, commute, or ride for fun with the lightweight Alpha Gold Aluminum frame, 2x9 speeds, and semi-skinny tires that are fast on the road and stable on loose terrain.

For the commuters, students and shopping at the market, there are mounts for a rear rack to carry pannier bags

Fitness enthusiasts will love adding Bontrager's DuoTrap to their frame (sold separately) that tracks fitness progress to their bike computer or phone to share on fitness apps such as Strava.

Is fitness a really big priority? Check out FX 3 with a carbon fork and a vibration-absorbing handlebar and ergonomic grips for more comfort. Plus FX 3's wide-range 11-46 cassette gives you all the gears you need to conquer hills and crush flats.

Due to supply-chain issues, Specs are subject to change without notice.

The stepthrough frame makes it easy to hop on and go, and hop off when your ride is over.

Built-in mounts make it easy to add racks, fenders and kickstands for versatility.

You can pair FX with your smartphone and send your ride data to your favorite fitness app (ie. Strava) when you add DuoTrap S.

bike frame with labeled dimensions
Bike Sizes:
SML
A. Reach 38.4cm 38.9cm 39.1cm
B. Stack 55.4cm 57.2cm 59.5cm
C. Standover 71.1cm 75.7cm 78.8cm
D. Effective Top Tube 53.7cm 55.3cm 56.8cm
E. Head Tube Angle 70.5° 70.5° 71.5°
F. Head Tube Length 13cm 15cm 17cm
G. Seat Tube Angle 74.5° 74.0° 73.5°
H. Seat Tube Length 38.1cm 44.5cm 50.8cm
I. Bottom Bracket Height 29.6cm 29.6cm 29.6cm
J. Bottom Bracket Drop 6.5cm 6.5cm 6.5cm
K. Fork Rake/Offset 5cm 5cm 5cm
L. Trail 7.5cm 7.5cm 6.8cm
M. Wheelbase 105.5cm 106.7cm 106.7cm
O. Chainstay Length 45cm 45cm 45cm

Sizing

Specs

Frame Alpha Gold Aluminum, stagger top tube, DuoTrap S compatible, internal cable routing, flat mount disc, rack & fender mounts, 135x5mm QR
Fork FX Alloy, flat mount disc, rack mounts, 405mm axle-to-crown, ThruSkew 5mm QR
Rims Bontrager Connection, alloy, double-wall, 32-hole, schrader valve
Hubs Front: Formula DC-20, alloy, 6-bolt, 5x100mm QR
Rear: Formula DC-22, alloy, 6-bolt, Shimano 8/9/10 freehub, 135x5mm QR
Tires Bontrager H2 Comp, wire bead, 30tpi, 700x35c
Crankset Forged alloy, 46/30, chainguard, 170mm length
Shifters Shimano Altus M2010, 9 speed
Front Derailleur Shimano Acera T3000, 34.9mm clamp, top swing, dual pull
Rear Derailleur Shimano Altus M2000, long cage
Cassette/Freewheel Shimano HG200, 11-36, 9 speed
Chain KMC X9
Brakes Tektro HD-R280 hydraulic disc, flat mount, 160mm rotor
Handlebars Bontrager alloy, 31.8mm, 15mm rise
Tape/Grips Bontrager Satellite
Stem Bontrager alloy, 31.8mm, Blendr compatible,
Headset 1-1/8'' threadless, sealed cartridge bearings
Seatpost Bontrager alloy, 27.2mm, 12mm offset, 330mm length
Saddle Bontrager Sport Women's
Pedals Bontrager City pedals
Weight M - 11.63 kg / 25.64 lbs

* Subject to change without notice.

Part Numbers

Option UPC MPN Store SKU
Satin Lithium Grey / Small 601842568958 5258286 BIK531226722
Satin Lithium Grey / Medium 601842568941 5258288 BIK532709172
Satin Lithium Grey / Large 601842568934 5258290 BIK538564962
Satin Viper Red / Medium 601842568910 5258294 BIK505374132
