Garmin GPSMAP 66sr - Multi-Band GPS Handheld with Sensors and Topo Maps

Garmin GPSMAP® 66sr - Multi-Band GPS Handheld with Sensors and Topo Maps
$699.99
Please select options Unavailable
In Store / Curbside Pickup Only. Bike Orders are typically ready in 2 – 5 days*. *Bikes may need to be built or transferred from another location. This may add extra processing time.

Details

NAVIGATE YOUR NEXT ADVENTURE
Whether you’re hiking, hunting, climbing, geocaching, kayaking or mountain biking, explore more by using this premium, rugged handheld with a 3” color display, preloaded maps and multi-band frequency support providing you with the best possible positioning technology.

No squinting necessary with this large, sunlight-readable color display.

Multi-band technology and expanded GNSS satellite support guide the way in challenging locations.

Maps as pretty as a picture and just as detailed —without a subscription.

See the peaks and valleys clearly with TopoActive maps for the U.S. and Canada.

Having Active Weather is like having your own personal weather forecaster on your journey1.

Explore more with up to 36 hours of battery life in GPS mode and up to 450 hours in Expedition mode.

General
PHYSICAL DIMENSIONS 2.5" x 6.4" x 1.4" (6.2 x 16.3 x 3.5 cm)
DISPLAY SIZE 1.5"W x 2.5"H (3.8 x 6.3 cm); 3" diag (7.6 cm)
DISPLAY RESOLUTION 240 x 400 pixels
DISPLAY TYPE transflective color TFT
WEIGHT

8.1 oz (230 g) with batteries
BATTERY TYPE Rechargeable, internal lithium-ion
BATTERY LIFE

Up to 36 hours
Up to 450 hours in expedition mode
WATER RATING IPX7
MIL-STD-810 yes (thermal, shock, water)
HIGH-SENSITIVITY RECEIVER Yes
INTERFACE high speed micro USB and NMEA 0183 compatible
MEMORY/HISTORY 16 GB (user space varies based on included mapping)

Maps & Memory
PRELOADED MAPS

yes (TopoActive; routable)
ABILITY TO ADD MAPS
Yes
BASEMAP
Yes
AUTOMATIC ROUTING (TURN BY TURN ROUTING ON ROADS) FOR OUTDOOR ACTIVITIES
Yes
MAP SEGMENTS 15000
BIRDSEYE yes (direct to device)
INCLUDES DETAILED HYDROGRAPHIC FEATURES (COASTLINES, LAKE/RIVER SHORELINES, WETLANDS AND PERENNIAL AND SEASONAL STREAMS)
Yes
INCLUDES SEARCHABLE POINTS OF INTERESTS (PARKS, CAMPGROUNDS, SCENIC LOOKOUTS AND PICNIC SITES)
Yes
DISPLAYS NATIONAL, STATE AND LOCAL PARKS, FORESTS, AND WILDERNESS AREAS
Yes
EXTERNAL MEMORY STORAGE yes (32 GB max microSD™ card)
WAYPOINTS/FAVORITES/LOCATIONS 10000
TRACKS 250
TRACK LOG 20000 points, 250 saved gpx tracks, 300 saved fit activities
ROUTES 250, 250 points per route; 50 points auto routing

Sensors
GPS
Yes
GLONASS
Yes
GALILEO
Yes
QZSS
Yes
BAROMETRIC ALTIMETER
Yes
COMPASS Yes (tilt-compensated 3-axis)
GPS COMPASS (WHILE MOVING)
Yes
MULTI-BAND FREQUENCY SUPPORT
Yes

Daily Smart Features
CONNECT IQ™ (DOWNLOADABLE WATCH FACES, DATA FIELDS, WIDGETS AND APPS)
SMART NOTIFICATIONS ON HANDHELD
VIRB® REMOTE
PAIRS WITH GARMIN CONNECT™ MOBILE
ACTIVE WEATHER

Safety and Tracking Features
LIVETRACK
Yes

Outdoor Recreation
POINT-TO-POINT NAVIGATION
Yes
COMPATIBLE WITH BASECAMP™
Yes
AREA CALCULATION
Yes
HUNT/FISH CALENDAR
Yes
SUN AND MOON INFORMATION
Yes
XERO™ LOCATIONS
Yes
GEOCACHING-FRIENDLY yes (Geocache Live)
CUSTOM MAPS COMPATIBLE yes (500 custom map tiles)
PICTURE VIEWER
Yes
INREACH REMOTE WIDGET
Yes
LED BEACON FLASHLIGHT
Yes

Outdoor Applications
COMPATIBLE WITH GARMIN EXPLORE™ APP
Yes
GARMIN EXPLORE WEBSITE COMPATIBLE
Yes

Connections
WIRELESS CONNECTIVITY

yes (Wi-Fi®, BLUETOOTH®, ANT+®)

EXPANDED GNSS SUPPORT

Access multiple global navigation satellite systems (GPS, GLONASS, GALILEO and QZSS) to track in more challenging environments.

MULTI-BAND FREQUENCY SUPPORT

Receive and utilize multiple frequencies sent by navigation satellites which enables improved user position accuracy, specifically in areas where GNSS signals are reflected, weak or typically do not penetrate. Get superior accuracy using state of the art technology, previously only available to the military.

ABC SENSORS

Navigate every trail with ABC sensors, including an altimeter for elevation data, barometer to monitor weather and 3-axis electronic compass.

BIRDSEYE SATELLITE IMAGERY

Download high-resolution photo-realistic maps directly to your device without an annual subscription. Easily find trails, pick stand locations, find parking, create waypoints and more.

PRELOADED TOPO MAPS

Preloaded TopoActive U.S. and Canada maps show you terrain contours, topographic elevations, summits, parks, coastlines, rivers, lakes and geographical points.

PUBLIC LAND BOUNDARIES

Optional display of federal public land boundaries on topographical maps helps you know that you’re venturing where you’re supposed to be.

ACTIVE WEATHER

When paired with your compatible smartphone, you can get real-time forecast information and live weather radar, so you’re aware of the surrounding conditions1.

WIKILOC TRAILS

This preloaded app lets you easily download hiking, cycling and other Wikiloc trails shared by outdoor enthusiasts like you. Get a free 60-day Wikiloc Premium trial to try this and other exclusive features. Learn more.

  • GPSMAP 66sr
  • USB cable
  • Carabiner clip
  • Documentation

Videos

GPSMAP® 66sr

Part Numbers

UPC Store SKU
753759257774 HAN373218460
